LAM M1343031 Stepper Motor

LAM M1343031 Stepper Motor

Model: M1343031 Stepper Motor

$294.00

NEMA34 Stepper Motor 6.8Nm (963oz-in) 7.1Arms L=98mm (3.86in)

Technical Data

Bipolar Holding Torque	6.8Nm (963oz-in)
Bipolar Phase Current	7.1Arms parallel connection 3.5Arms series connection
Rotor Inertia	1550g-cm² (8.46oz-in²)
Length	98mm (3.86inches)
Weight	3000g (106oz)
Flange	NEMA 34 86x86mm (3.39x3.39inches)
Leads Number	8
Full step angle	1.8°

Model: M1343031 Stepper Motor
Weight: 8lbs
Manufacturer: Lam Technologies
